Model	Nominal Airflow* (m³/h)	Number of Filter Cartridges	Filter Element Height（mm）	Filter Area(m)			Motor(KW)	Shipping Weight（kg)	Dimensions				Noise Level**dB(A)
				Water	Oil	Smoke			A	B	CAfternoon Filtration	Cwith Post-filtration	Afternoon Filtration	with Post-filtration
WSO 10	765	1	254	4.6	4.0	—	#0.75(50Hz)/0.55(60Hz)	82	483	503	843	927	66	63
WSO 15	1445	1	381	11.6	10.1	7.9	1.1	114	610	579	1047	1130	70	68
WSO 20	2090	1	508	15.5	13.6	10.5	2.2	130	711	630	1247	1539	68	70
WSO 20(FM)	2090	1	508	15.5	13.6	10.5	2.2	175	711	630	2096	2454	68	70
WSO 25-1	3145	1	635	26.6	22.8	17.2	2.2	341	762	770	2677	2903	71	69
WS0 25-2	6290	2	635	53.2	44.6	36.3	＋	455	1544	770	2223	2733	＋	＋
WS0 25-3	9435	3	635	79.8	68.3	54.4	＋	605	2306	770	2223	2733	＋	＋
* Based on dean fiers. * Published dB(A).sound pressure levels were made in a hemi-anechoic chamber.Units were run with clean filters and maximum airflow through approwmately 10 feet of ducting connected to an inlet plenum.Measurements were made 1.5 meters off the ground,1meter away from the collector ,on the filter door side of the mist collector.Actual installed equipment sound pressure levels wills vary depending upon the measurement location,the operating conditions, the installation, and the surrounding environment. * Optioned fans available.See optional fan specifications for sound leved data.
