Waste Gas Treatment Equipment >> Scrubber

Washing tower exhaust gas treatment system

Washing tower is mainly Uaed to treat acid waste Gas (such as HCI、HNO3、HCN、H2CrO4、 HF、 H2SO4、Cl2etc.).the cylindrical Structure has high design Strength. Small drag Coeficlent. Low pressure and high treatment eficiency. The space occupled by the amall space is go-nerally adopted for this type of medum and low wind volume. The defog-ging layer has a capacity of 99% to remove water vapor of 7 µm or more.Which is the most commonly used washing tower in the waste gas treatment projects.Corroaion Resia-tance such as pp/pvc/frpis uaed for the materlal selection.

Contact immediately
Washing tower exhaust gas treatment system
Product Information

Product Introduction

Specifications

Item No. Model Airflow/CMH A/mm B/mm C/mm H/mm
1 DEG-FJTVS-O30 2500 300 300 600 4100
2 DEG-FJTVS-040 5000 400 400 850 4200
3 DEG-FJTVS-O50 7500 500 500 1050 4300
4 DEG-FJTVS-O55 10000 550 550 1200 4350
5 DEG-FJTVS-060 12500 600 600 1350 4600
6 DEG-FJTVS-065 15000 650 650 1450 4650
7 DEG-FJTVS-O7O 17500 700 700 1600 4700
8 DEG-FJTVS-075 20000 750 750 1700 4750
9 DEG-FJTVS-O8O 22500 800 800 1800 4900
10 DEG-FJTVS-O85 25000 850 850 1900 4950
11 DEG-FJTVS-090 27500 900 900 2000 5000
12 DEG-FJTVS-O95 30000 950 950 2100 5050
13 DEG-FJTVS-1O0 32500 1000 1000 2150 5100
14 DEG-FJTVS-105 35000 1050 1050 2250 5150
